Product description
【Weiye Annular Lime Kiln】
The performance of Weiye Annular Lime Kiln is far better than the firing sleeve kiln, also known as "ring kiln", especially the heat consumption index and the degree of automation, the kiln specifications are 100 tons per day, 200 tons, 300 tons, 400 tons, 500 tons, 600 tons, 800 tons, etc., the main kiln type is 600 tons.
Weiye Annular Lime Kiln is a kind of shaft kiln with upper and lower inner sleeves in the shell, and the charge is calcined in the annular space of the inner and outer cylinder.
【Weiye Annular Lime Kiln - process principle】：
The inner structure of Weiye Annular Lime Kiln from top to bottom is material storage/preheating zone, upper calcination zone, lower calcination zone (and flow zone), and cooling/ash discharge zone. After sifting the raw material stone, it is sent to the kiln roof by the lifting hopper, and then distributed to the kiln by the rotary distributor. The preheated raw stone flows into the upper calcination zone along the annular charge space, where the raw stone is effectively decarburized. The calcined lime, which has been basically burned in the upper calcined zone, flows into the lower calcined zone, that is, the parallel flow zone, where it is effectively homogenized. The homogenized lime flows into the cooling belt, and then is pushed into the lime hopper at the bottom of the kiln by the pusher platform, from the hopper into the transfer belt machine to carry away.
【Weiye Annular Lime Kiln -- technical characteristics】：
1. Effectively reduce the thickness of the material layer, making the kiln body better gas permeability;
2. The stone through the arch bridge has gone through a complete tumbling, calcination is more uniform;
3. Due to the existence of the combustion chamber, the calcining flame is not directly in contact with the material, mainly through heat transfer by thermal radiation, and the fuel is more adaptable;
4. Through the effective heat exchange mechanism to recover heat, reduce heat consumption;
5. The reverse and co-flow calcining process is carried out in a kiln, which effectively solves the problem of over-burning, improves the activity of lime, and stabilizes at 360ml;
6. High degree of self-control, can achieve full automatic control;
7. The production flexibility range is large, up to 50%~110%;
8. The whole kiln body is operated under negative pressure, which is conducive to lime calcination and more environmentally friendly.
